HTS E201
HTS E201
End Mill
HTS E201
| Steel | ||
| Stainless Steel | ||
| Hardened Steel ≤52 HRc | ||
| Hardened Steel >52 HRc | ||
| Cast Iron | ||
| Graphite | ||
| Non Ferrous Material | ||
| HRSA | ||
| Titanium |
Recommended
Acceptable
Not Recommended
| CODE | d1(mm) | d2(mm) | d3(mm) | L1(mm) | L2(mm) | L3(mm) | Corner |
|---|---|---|---|---|---|---|---|
| E201 Ø3X6XØ6X58 Z2 | 3 | 6 | 2.70 | 58 | 6 | 12 | Ch 0.10 |
| E201 Ø4X6XØ6X58 Z2 | 4 | 6 | 3.70 | 58 | 6 | 12 | Ch 0.15 |
| E201 Ø5X8XØ6X58 Z2 | 5 | 6 | 4.70 | 58 | 8 | 15 | Ch 0.17 |
| E201 Ø6X8XØ6X58 Z2 | 6 | 6 | 5.70 | 58 | 8 | 16 | Ch 0.15 |
| E201 Ø8X10XØ8X64 Z2 | 8 | 8 | 7.40 | 64 | 10 | 20 | Ch 0.17 |
| E201 Ø10X12XØ10X73 Z2 | 10 | 10 | 9.40 | 73 | 12 | 30 | Ch 0.15 |
| E201 Ø12X15XØ12X82 Z2 | 12 | 12 | 11.40 | 82 | 15 | 30 | Ch 0.15 |
* Upon customer request, cutting tools can be manufactured in custom dimensions in
addition to the above dimensions.
** Upon customers request, different types of coatings can be applied.
** Upon customers request, different types of coatings can be applied.
